SKU: WLT16-60-500-DURB
Durbal WLT16-60-500 Stainless Steel Spherical Plain Bearing with Cage 16x42x21mm
Durbal WLT16-60-500 Stainless Steel Spherical Plain Bearing with Cage 16x42x21mm
Out of stock
Share this product
Description
Description
DURBAL Heavy-Duty Caged Stainless Steel Spherical Bearings with Integral Self-Aligning Roller Bearing: These spherical bearings are made from hardened and super finished stainless steel. For high speeds, wide swivelling angles or rotating movements. Suitable for high loads. Low maintenance due to long-term lubrication with food-grade approval. Covering discs in stainless steel on both sides to prevent the penetration of coarse dirt particles inside the bearing. Temperature range: -45 deg C to +120 deg C.
- Brand / Quality:
- Durbal - High Quality
- Inside Diameter:
- 16mm
Technical
Technical
| d | 16mm |
|---|---|
| D | 42mm |
| B | 21mm |
| C | 15mm |
| d1 | 19mm |
| tilt angle α | 8 deg |
| weight | 0.13kg |
| rotational speed limit n max | 975 min-1 |
| basic load rating dyn C | 9.31 kN |
| basic load rating stat Co | 6.23 kN |
| radial clearance CN | 10-30 µm |
