SKU: UELFL205-100D1-NTN
NTN UELFL205-100D1 Imperial Two Bolt Cast Iron Oval Housing with 1 inch Bore Eccentric Collar Insert - Allow 2-3 Days
NTN UELFL205-100D1 Imperial Two Bolt Cast Iron Oval Housing with 1 inch Bore Eccentric Collar Insert - Allow 2-3 Days
Out of stock
Share this product
Description
Description
UELFL200 Series 2 Bolt Cast Iron Oval Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has an eccentric collar to allow tightening against the shaft once fitted. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, eccentric collar fixing
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 25.4mm = 1 Inch
- Style:
- UELFL
- Bolt Hole Centres:
- 3-57/64 inch
Technical
Technical
| Shaft diameter | 1 inch |
|---|---|
| H | 5-1/8 inch |
| J | 3-57/64 inch |
| A<sub>2</sub> | 5/8 inch |
| A<sub>1</sub> | 1/2 inch |
| A | 1-1/16 inch |
| N | 5/8 inch |
| L | 2-11/16 inch |
| A<sub>0</sub> | 1-11/16 inch |
| B<sub>1</sub> | 1.748 inch |
| S | 0.687 inch |
| F min. | 1-1/2 inch |
| Fixing bolt | 1/2 inch |
| Mass | 1.5 lbs |
