SKU: UCFL319D1-NTN
NTN UCFL319D1 Metric Two Bolt Oval Cast Iron Flange Housing with 95mm Bore Insert - Allow 2-3 Days
NTN UCFL319D1 Metric Two Bolt Oval Cast Iron Flange Housing with 95mm Bore Insert - Allow 2-3 Days
Out of stock
Share this product
Description
Description
UCFL300 Series Heavy Duty 2 Bolt Oval Housings: These heavy-duty bearing units are supplied with a fully sealed bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts can be removed from the housing for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, grub screw fixing
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 95mm
- Style:
- UCFL
- Bolt Hole Centres:
- 330mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter | 95mm |
| H | 405mm |
| J | 330mm |
| A<sub>2</sub> | 59mm |
| A<sub>1</sub> | 40mm |
| A | 94mm |
| N | 41mm |
| L | 250mm |
| A<sub>0</sub> | 121mm |
| B | 103mm |
| S | 41mm |
| Fixing bolt | M36 |
| --- | Load rating |
| Dynamic load C<sub>r</sub> | 169 kN |
| Static load C<sub>0r</sub> | 119 kN |
| Fatigue load limit C<sub>u</sub> | 7.65 kN |
| --- | Unit information |
| Mass | 23 kg |
