SNR UCC212 Metric Cast Iron Cartridge Unit with 60mm Bore Insert 38mm Outside Dia - Allow 2-3 Days
SNR UCC212 Metric Cast Iron Cartridge Unit with 60mm Bore Insert 38mm Outside Dia - Allow 2-3 Days
Regular price
€81,95
ex VAT
Regular price
Sale price
€81,95
ex VAT
In stock
Price Break
3+
€62,06
4+
€58,57
9+
€57,87
19+
€57,18
49+
€56,48
99+
€55,78
499+
€52,30
999+
€51,60
1999+
€50,90
2999+
€50,20
4999+
€48,81
Quantity
Couldn't load pickup availability
Share this product
Description
Description
UCC Series (Normal Duty) Cartridge Bearing Unit: Cast iron cartridge bearing unit supplied with a full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. Cartridge units allow a self aligning bearing inserts to be used where a fixed bearing would normally be used.
The insert can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, full width insert
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 60mm
- Style:
- UCC
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter d | 60mm |
| A | 38mm |
| A3 | 2mm |
| B | 65.1mm |
| H | 130mm |
| S | 25.4mm |
| G | M6x1 |
| --- | Load rating |
| Dynamic load C | 52.5 kN |
| Static load C0 | 32.8 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Mass | 2.53 kg |
