SKU: UC.218.TS.CHAL

Challenge UC218 Metric Insert with Grub Screws with 90mm Bore 160mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use

Challenge UC218 Metric Insert with Grub Screws with 90mm Bore 160mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
Regular price €374,95 ex VAT
Regular price Sale price €374,95 ex VAT
Sale Sold out

Equivalent to: UC.218

In stock

Price Break
3+ €284,91
5+ €268,91
9+ €265,71
19+ €262,50
49+ €259,30
74+ €256,10
99+ €240,10
199+ €236,89
249+ €233,69
499+ €230,49
999+ €224,09
Quantity

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
Shaft Diameter d 90mm
Outside Diameter D 160mm
Overall Width Bi 96mm
Inner Race Width Be 37mm
Back of Bearing to Centre Line n 39.7mm
Front of Bearing to Centre Line m 56.3mm
Dimension G 12mm
Load Rating (Dynamic) 7500kg
Load Rating (Static) 6170kg
Max Speed 950 rev/min
Grease Nipple Thread Size M10
Working Temperature -30°C to +120°C
