SKU: UC.207.TS.CHAL

Challenge UC207 Metric Insert with Grub Screws with 35mm Bore 72mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use

Challenge UC207 Metric Insert with Grub Screws with 35mm Bore 72mm Outside Dia and Triple Lip Seal Ideal for Agricultural and Outdoor Use
Regular price €24,95 ex VAT
Regular price Sale price €24,95 ex VAT
Sale Sold out

Equivalent to: UC.207-20

In stock

Price Break
3+ €18,81
5+ €17,75
9+ €17,54
19+ €17,33
49+ €17,12
74+ €16,90
99+ €15,85
199+ €15,64
249+ €15,43
499+ €15,21
999+ €14,79
Quantity

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
Shaft Diameter d 35mm
Outside Diameter D 72mm
Overall Width Bi 42.9mm
Inner Race Width Be 20mm
Back of Bearing to Centre Line n 17.5mm
Front of Bearing to Centre Line m 25.4mm
Dimension G 7mm
Grub Screws x 2 M8x1.0mm
Load Rating (Dynamic) 2010kg
Load Rating (Static) 1390kg
Max Speed 2400 rev/min
Grease Nipple Thread Size M6
Working Temperature -30°C to +120°C
