SKU: TSF12.1C-ISB
ISB TSF12.1C Right Hand Maintenance Free Steel/PTFE Lined Plain Female Rod End M12 Thread
ISB TSF12.1C Right Hand Maintenance Free Steel/PTFE Lined Plain Female Rod End M12 Thread
Equivalent to: TSF12.1C
Out of stock
Share this product
Description
Description
TSF - TSM Series Rod End Bearings:: This series is constructed with C 45 improved and forged steel; the surfaces are protected from external corrosive agents, thanks to a galvanised zinc covering. They are available with internal and external threading, to the right and the left and they are provided with greasers or bores for lubrication.
- Brand / Quality:
- ISB-Good Quality
- Thread Size:
- M12x1.25
- Thread M / F:
- Female
- Thread Direction:
- Right Hand
- Bore:
- 12
- Inside Diameter:
- 12
- Material:
- Steel/PTFE Lined
Technical
Technical
| d | 12mm |
|---|---|
| d1 | 15.4mm |
| d2 | 32mm |
| d3 | M 12x1.25mm |
| d4 | 17.5mm |
| d5 | 22mm |
| dk | 22.23mm |
| B | 16mm |
| C1 | 12.5mm |
| D | 26mm |
| h1 | 50mm |
| I3 | 18mm |
| I4 | 67mm |
| I5 | 6.5mm |
| I7 | 17mm |
| W | 18mm |
| α | 13° |
| r 1s min | 0.3Nmax Min -1 |
| Dynamic C | 14KN |
| Static C0 | 19KN |
| Weight | 0.12Kg |
