• SKF TKBA40 Quick and Accurate Belt Alignment Tool
1 1

SKU: TKBA40-SKF

SKF TKBA40 Quick and Accurate Belt Alignment Tool

SKF TKBA40 Quick and Accurate Belt Alignment Tool
€2.063,95 ex VAT
€2.063,95 ex VAT
Sale Sold out

In stock

Price Break
10+ €1.568,01
19+ €1.479,92
29+ €1.462,30
39+ €1.444,68
49+ €1.427,06
74+ €1.409,45
99+ €1.321,36
199+ €1.303,74
249+ €1.286,12
499+ €1.268,50
999+ €1.233,27

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF TKBA40 Belt Alignment Tool: The SKF TKBA 40 aligns V-belt pulleys in the grooves. V–guides and powerful magnets allow the TKBA 40 to be fitted in the grooves of the pulley. With only two components, a laser–emitting unit and a receiver unit, the belt alignment tool is easy and fast to attach. The three–dimensional target area on the receiver unit allows the easy detection of misalignment as well as its nature; whether it is horizontal, vertical, parallel or a combination of all three. Powerful magnets allow fast and easy attachment.
Note: Highly accurate tool for V-belt pulley alignment
Brand / Quality:
SKF - High Quality
Technical
Type of Laser Red laser diode
Lase x1 Built-in class 2 laser, <1 mW, 632mm
Laser Line Length 3m at 2m (9.8ft at 6.6ft)
Measurement Accuracy Angular Better than 0.2c
Measurement Accuracy Offset Better than 0.5mm (0.02 in.)Measurement Distance
50mm to 6000mm (2in. to 20ft) Control
Laser on/off switch Housing Material
Extruded aluminium Dimensions
Transmitter Unit 70x74x61mm (2.8 x 2.9 x 2.4 in.)
Receiver Unit 96x74x61mm (3.8 x 2.9 x 2.4 in.)
Mounting Magnetic, groove mounted
V-guides Size 1: 22 mm, short rods (3x pairs), Size 2: 22 mm, long rods (3x pairs), Size 3: 40 mm, short rods (3x pairs), Size 4: 40 mm, long rods (3x pairs)
Battery 2x AA Alkaline type IEC LR03
Operation Time 20 hours continuous operation
Operating Temperature 0 to 40c
IP rating IP 40
