• SS20DP/13B-0.3125 Imperial EN8 Steel Spur Gear 13 Tooth 20 DP Bored 0.3125 inch (H8)
1 1

SKU: SS20DP/13B-0.3125_INCH

SS20DP/13B-0.3125 Imperial EN8 Steel Spur Gear 13 Tooth 20 DP Bored 0.3125 inch (H8)

SS20DP/13B-0.3125 Imperial EN8 Steel Spur Gear 13 Tooth 20 DP Bored 0.3125 inch (H8)
€42,95 ex VAT
€42,95 ex VAT
Sale Sold out

In stock

Price Break
5+ €32,22
9+ €30,41
19+ €30,05
29+ €29,68
49+ €29,32
74+ €28,96
99+ €27,15
199+ €26,79
249+ €26,43
499+ €26,06
999+ €25,34

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
GEAR_IMP_S_DESC
Brand / Quality:
Drive-Flex - High Quality
Bore:
7.93mm = 0.312 (5/16) inch
Number of Teeth:
13
Variant:
Tooth Profile B
Pitch Circle Diameter:
16.51mm = 0.65 inch
Gear Modulus:
20DP
Technical
Number of Teeth 13
Pitch (dp) 0.65 inch
Bore (H8) 0.3125 inch
Hub / Boss (dm) 0.47 inch
Outside (de) 0.75 inch
Width (A) 0.75 inch
Face Width (B) 0.375 inch
Modulus / Diametral Pitch DP 20 dp
Tolerance unless otherwise stated +- 0.01 inch
Pressure Angle 20 degrees
