• SNR EXFE214 Metric Four Bolt Square Cast Iron Flange Housing with 70mm Bore Eccentric Collar Insert - Allow 2-3 Days
1 1

SKU: EXFE214-SNR

SNR EXFE214 Metric Four Bolt Square Cast Iron Flange Housing with 70mm Bore Eccentric Collar Insert - Allow 2-3 Days

SNR EXFE214 Metric Four Bolt Square Cast Iron Flange Housing with 70mm Bore Eccentric Collar Insert - Allow 2-3 Days
€131,95 ex VAT
€131,95 ex VAT
Sale Sold out

In stock

Price Break
3+ €100,09
4+ €94,46
9+ €93,34
19+ €92,21
49+ €91,09
99+ €89,96
499+ €84,34
999+ €83,22
1999+ €82,09
2999+ €80,97
4999+ €78,72

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
H7DNO3QCDC
Brand / Quality:
SNR - High Quality
Inside Diameter:
70mm
Style:
EXFE
Bolt Hole Centres:
150mm
Technical
--- Dimensions
Shaft diameter 70mm
A 56mm
A1 18mm
A2 89.6mm
B 68.2mm
B1 85.7mm
d1 96.8mm
e 38mm
J 150mm
L 188mm
N 18mm
S 34.1mm
G R1/8″
--- Load rating
Dynamic load C 62 kN
Static load C0 45 kN
--- Unit information
Operating temperature min. -20°C
Operating temperature max. 100°C
Recommended tightening torque for set screw 22 Nm
Mass 6.65 kg
