• SNR EXF312 Metric Four Bolt Square Cast Iron Flange Housing with 60mm Bore Eccentric Collar Insert
1 1

SKU: EXF312-SNR

SNR EXF312 Metric Four Bolt Square Cast Iron Flange Housing with 60mm Bore Eccentric Collar Insert

SNR EXF312 Metric Four Bolt Square Cast Iron Flange Housing with 60mm Bore Eccentric Collar Insert
€152,95 ex VAT
€152,95 ex VAT
Sale Sold out

In stock

Price Break
3+ €115,82
4+ €109,31
9+ €108,01
19+ €106,71
49+ €105,41
99+ €104,11
499+ €97,60
999+ €96,30
1999+ €95,00
2999+ €93,69
4999+ €91,09

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCF200_DESC
Brand / Quality:
SNR - High Quality
Inside Diameter:
60mm
Style:
EXF
Bolt Hole Centres:
150mm
Technical
--- Dimensions
Shaft diameter d 60mm
A 56mm
A1 22mm
A2 81.45mm
B 61.9mm
B1 79.4mm
d1 89mm
e 33mm
J 150mm
L 193mm
N 23mm
S 30.95mm
G M6x1
--- Load rating
Dynamic load C 81.6 kN
Static load C0 51.8 kN
--- Unit information
Operating temperature min. -20°C
Operating temperature max. 100°C
Recommended tightening torque for set screw 22 Nm
Mass 6.62 kg
