• SNR EXF214 Metric Four Bolt Square Cast Iron Flange Housing with 70mm Bore Eccentric Collar Insert - Allow 2-3 Days
1 1

SKU: EXF214-SNR

SNR EXF214 Metric Four Bolt Square Cast Iron Flange Housing with 70mm Bore Eccentric Collar Insert - Allow 2-3 Days

SNR EXF214 Metric Four Bolt Square Cast Iron Flange Housing with 70mm Bore Eccentric Collar Insert - Allow 2-3 Days
€131,95 ex VAT
€131,95 ex VAT
Sale Sold out

In stock

Price Break
3+ €100,09
4+ €94,46
9+ €93,34
19+ €92,21
49+ €91,09
99+ €89,96
499+ €84,34
999+ €83,22
1999+ €82,09
2999+ €80,97
4999+ €78,72

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCF200_DESC
Brand / Quality:
SNR - High Quality
Inside Diameter:
70mm
Style:
EXF
Bolt Hole Centres:
152mm
Technical
--- Dimensions
Shaft diameter d 70mm
A 54mm
A1 22mm
A2 82.6mm
B 68.2mm
B1 85.7mm
d1 96.8mm
e 31mm
J 152mm
L 193mm
N 19mm
S 34.1mm
G M10x1
--- Load rating
Dynamic load C 62 kN
Static load C0 45 kN
--- Unit information
Operating temperature min. -20°C
Operating temperature max. 100°C
Recommended tightening torque for set screw 22 Nm
Mass 6.73 kg
