• SNR EXF212 Metric Four Bolt Square Cast Iron Flange Housing with 60mm Bore Eccentric Collar Insert - Allow 2-3 Days
1 1

SKU: EXF212-SNR

SNR EXF212 Metric Four Bolt Square Cast Iron Flange Housing with 60mm Bore Eccentric Collar Insert - Allow 2-3 Days

SNR EXF212 Metric Four Bolt Square Cast Iron Flange Housing with 60mm Bore Eccentric Collar Insert - Allow 2-3 Days
€89,95 ex VAT
€89,95 ex VAT
Sale Sold out

In stock

Price Break
3+ €67,97
4+ €64,15
9+ €63,38
19+ €62,62
49+ €61,86
99+ €61,09
499+ €57,28
999+ €56,51
1999+ €55,75
2999+ €54,98
4999+ €53,46

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCF200_DESC
Brand / Quality:
SNR - High Quality
Inside Diameter:
60mm
Style:
EXF
Bolt Hole Centres:
143mm
Technical
--- Dimensions
Shaft diameter d 60mm
A 48mm
A1 18mm
A2 75.8mm
B 61.8mm
B1 77.7mm
d1 82mm
e 29mm
J 143mm
L 175mm
N 19mm
S 30.9mm
G M6x1
--- Load rating
Dynamic load C 52.5 kN
Static load C0 32.8 kN
--- Unit information
Operating temperature min. -20°C
Operating temperature max. 100°C
Recommended tightening torque for set screw 22 Nm
Mass 4.7 kg
