• SNR ESFLE209 Metric Two Bolt Cast Iron Oval Housing with 45mm Bore Eccentric Collar Insert - Allow 2-3 Days
1 1

SKU: ESFLE209-SNR

SNR ESFLE209 Metric Two Bolt Cast Iron Oval Housing with 45mm Bore Eccentric Collar Insert - Allow 2-3 Days

SNR ESFLE209 Metric Two Bolt Cast Iron Oval Housing with 45mm Bore Eccentric Collar Insert - Allow 2-3 Days
€47,95 ex VAT
€47,95 ex VAT
Sale Sold out

In stock

Price Break
3+ €36,03
4+ €34,01
9+ €33,60
19+ €33,20
49+ €32,79
99+ €32,39
499+ €30,36
999+ €29,96
1999+ €29,55
2999+ €29,15
4999+ €28,34

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
7UHIEJ23TO
Brand / Quality:
SNR - High Quality
Inside Diameter:
45mm
Style:
ESFLE
Bolt Hole Centres:
148.5mm
Technical
--- Dimensions
Shaft diameter d 45mm
A 37.5mm
A1 13mm
A2 56.7mm
B 30.2mm
B1 43.7mm
d1 62mm
e 24mm
H 180mm
J 148.5mm
L 111mm
N 14mm
S 11mm
G R1/8″
--- Load rating
Dynamic load C 31.85 kN
Static load C0 20.8 kN
--- Unit information
Operating temperature min. -20°C
Operating temperature max. 100°C
Recommended tightening torque for set screw 11.5 Nm
Mass 1.79 kg
