• SNR ESF210 Metric Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 50mm Bore - Allow 2-3 Days
1 1

SKU: ESF210-SNR

SNR ESF210 Metric Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 50mm Bore - Allow 2-3 Days

SNR ESF210 Metric Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 50mm Bore - Allow 2-3 Days
€58,95 ex VAT
€58,95 ex VAT
Sale Sold out

In stock

Price Break
3+ €44,61
4+ €42,10
9+ €41,60
19+ €41,10
49+ €40,60
99+ €40,10
499+ €37,59
999+ €37,09
1999+ €36,59
2999+ €36,09
4999+ €35,09

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
LXCMIG7NEM
Brand / Quality:
SNR - High Quality
Inside Diameter:
50mm
Style:
ESF
Bolt Hole Centres:
111mm
Technical
--- Dimensions
Shaft diameter d 50mm
A 40mm
A1 16mm
A2 54.7mm
B 30.2mm
B1 43.7mm
d1 67.2mm
e 22mm
J 111mm
L 143mm
N 16mm
S 11mm
G M6x1
--- Load rating
Dynamic load C 35.1 kN
Static load C0 23.2 kN
--- Unit information
Operating temperature min. -20°C
Operating temperature max. 100°C
Recommended tightening torque for set screw 11.5 Nm
Mass 2.5 kg
