• SNR ESF209 Metric Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 45mm Bore - Allow 2-3 Days
1 1

SKU: ESF209-SNR

SNR ESF209 Metric Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 45mm Bore - Allow 2-3 Days

SNR ESF209 Metric Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 45mm Bore - Allow 2-3 Days
€51,95 ex VAT
€51,95 ex VAT
Sale Sold out

In stock

Price Break
3+ €39,46
4+ €37,25
9+ €36,80
19+ €36,36
49+ €35,91
99+ €35,47
499+ €33,25
999+ €32,81
1999+ €32,37
2999+ €31,92
4999+ €31,04

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
LXCMIG7NEM
Brand / Quality:
SNR - High Quality
Inside Diameter:
45mm
Style:
ESF
Bolt Hole Centres:
105mm
Technical
--- Dimensions
Shaft diameter d 45mm
A 38mm
A1 16mm
A2 54.7mm
B 30.2mm
B1 43.7mm
d1 62mm
e 22mm
J 105mm
L 137mm
N 16mm
S 11mm
G M6x1
--- Load rating
Dynamic load C 31.85 kN
Static load C0 20.8 kN
--- Unit information
Operating temperature min. -20°C
Operating temperature max. 100°C
Recommended tightening torque for set screw 11.5 Nm
Mass 2.13 kg
