SKU: C4060K30M-SKF

SKF C4060K30M Carb Toroidal Roller Bearing with Taper Bore 300x460x160mm Allow 7-10 Days

Name: SKF C4060K30M Carb Toroidal Roller Bearing with Taper Bore 300x460x160mm Allow 7-10 Days
Brand: SKF
SKU: C4060K30M-SKF
Availability: OutOfStock

Out of stock

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF Carb Toroidal Roller Bearings: These compact design bearings have a single row of barrel shaped (spherical) rollers which run on a common spherical outer and inner raceway. Their design offers many features such as self alignment, insensitivity to misalignment, tolerance to heavy radial and axial loads etc. They are manufactured with in both parallel and tapered bore variants and the ability to deliberately displace the position of the rings to each other permits accurate setting of the radial internal clearance.
Benefits: High radial and axial loads, misalignment, taper and parallel bore options

Brand / Quality:: SKF - High Quality
Inside Diameter:: 300mm
Outside Diameter:: 460mm
Width:: 160mm
Seals / Shields:: None

Technical

---	Dimensions
d	300mm
D	460mm
B	160mm
d2	338mm
D1	409mm
r1r2 min	4mm
s1	30.4mm
da min	315mm
da max	360mm
Da min	400mm
Da max	445mm
Ca	2.8mm
ra max	3mm
---	Speeds and Loads
Dynamic load C	2900 kN
Static load Co	4900 kN
Fatigue load limit Pu	380 kN
Reference speed	850 rpm
Limiting speed	1200 rpm
---	Factors
Misalignment factor k1	0.105
Operating clearance factor k2	0.106
---	Weights
Weight	95 kg
---	Matching Withdrawal Sleeves
Sleeve No.	<a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=AOH24060G+sleeve>AOH24060G</a>
