• SKF C3130K Carb Toroidal Roller Bearing with Taper Bore 150x250x80mm Allow 7-10 Days
1 1

SKU: C3130K-SKF

SKF C3130K Carb Toroidal Roller Bearing with Taper Bore 150x250x80mm Allow 7-10 Days

SKF C3130K Carb Toroidal Roller Bearing with Taper Bore 150x250x80mm Allow 7-10 Days
€2.736,95 ex VAT
€2.736,95 ex VAT
Sale Sold out

In stock

Price Break
10+ €2.079,58
19+ €1.962,75
29+ €1.939,38
39+ €1.916,02
49+ €1.892,65
74+ €1.869,29
99+ €1.752,46
199+ €1.729,09
249+ €1.705,72
499+ €1.682,36
999+ €1.635,63

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Carb Toroidal Roller Bearings: These compact design bearings have a single row of barrel shaped (spherical) rollers which run on a common spherical outer and inner raceway. Their design offers many features such as self alignment, insensitivity to misalignment, tolerance to heavy radial and axial loads etc. They are manufactured with in both parallel and tapered bore variants and the ability to deliberately displace the position of the rings to each other permits accurate setting of the radial internal clearance.
Benefits: High radial and axial loads, misalignment, taper and parallel bore options
Brand / Quality:
SKF - High Quality
Inside Diameter:
150mm
Outside Diameter:
250mm
Width:
80mm
Seals / Shields:
None
Technical
--- Dimensions
d 150mm
D 250mm
B 80mm
d2 182mm
D1 226mm
r1r2 min 2.1mm
s1 13.9mm
da min 162mm
da max 195mm
Da min 215mm
Da max 238mm
Ca 2.3mm
ra max 2mm
--- Speeds and Loads
Dynamic load C 880 kN
Static load Co 1290 kN
Fatigue load limit Pu 122 kN
Reference speed 2000 rpm
Limiting speed 2800 rpm
--- Factors
Misalignment factor k1 0.12
Operating clearance factor k2 0.092
--- Weights
Weight 15 kg
--- Matching Adaptor Sleeves
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=H3130L+sleeve>H3130L</a>
--- Matching Withdrawal Sleeves
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=AHX3130G+sleeve>AHX3130G</a>
