• SKF C3040K Carb Toroidal Roller Bearing Taper Bore 180x310x82mm
1 1

SKU: C3040K-SKF

SKF C3040K Carb Toroidal Roller Bearing Taper Bore 180x310x82mm

SKF C3040K Carb Toroidal Roller Bearing Taper Bore 180x310x82mm
€2.629,95 ex VAT
€2.629,95 ex VAT
Sale Sold out

In stock

Price Break
10+ €1.998,10
19+ €1.885,85
29+ €1.863,40
39+ €1.840,95
49+ €1.818,50
74+ €1.796,05
99+ €1.683,79
199+ €1.661,34
249+ €1.638,89
499+ €1.616,44
999+ €1.571,54

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Carb Toroidal Roller Bearings: These compact design bearings have a single row of barrel shaped (spherical) rollers which run on a common spherical outer and inner raceway. Their design offers many features such as self alignment, insensitivity to misalignment, tolerance to heavy radial and axial loads etc. They are manufactured with in both parallel and tapered bore variants and the ability to deliberately displace the position of the rings to each other permits accurate setting of the radial internal clearance.
Benefits: High radial and axial loads, misalignment, taper and parallel bore options
Brand / Quality:
SKF - High Quality
Inside Diameter:
180mm
Outside Diameter:
310mm
Width:
82mm
Seals / Shields:
None
Technical
d 180mm
D 310mm
B 82mm
Dynamic load C 1120 kN
Static load Co 1730 kN
Fatigue load limit Pu 153 kN
Reference speed 1700 rpm
Limiting speed 2400 rpm
d2 235mm
d3 240mm
D1 285mm
B1 120mm
B2 31.5mm
s1 2.1mm
s2 15.2mm
da max 250mm
db min 210mm
Da min 275mm
Da max 299mm
Ba min 9mm
Ca min 2.9mm
ra max 2mm
Misalignment factor k1 0.123
Operating clearance factor k2 0.095
Weight 30 kg
