• SKF C2218K Carb Toroidal Roller Bearing with Taper Bore 90x160x40mm Allow 7-10 Days
1 1

SKU: C2218K-SKF

SKF C2218K Carb Toroidal Roller Bearing with Taper Bore 90x160x40mm Allow 7-10 Days

SKF C2218K Carb Toroidal Roller Bearing with Taper Bore 90x160x40mm Allow 7-10 Days
€471,95 ex VAT
€471,95 ex VAT
Sale Sold out

In stock

Price Break
10+ €358,35
19+ €338,22
29+ €334,19
39+ €330,16
49+ €326,14
74+ €322,11
99+ €301,98
199+ €297,95
249+ €293,93
499+ €289,90
999+ €281,85

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Carb Toroidal Roller Bearings: These compact design bearings have a single row of barrel shaped (spherical) rollers which run on a common spherical outer and inner raceway. Their design offers many features such as self alignment, insensitivity to misalignment, tolerance to heavy radial and axial loads etc. They are manufactured with in both parallel and tapered bore variants and the ability to deliberately displace the position of the rings to each other permits accurate setting of the radial internal clearance.
Benefits: High radial and axial loads, misalignment, taper and parallel bore options
Brand / Quality:
SKF - High Quality
Inside Diameter:
90mm
Outside Diameter:
160mm
Width:
40mm
Seals / Shields:
None
Technical
--- Dimensions
d 90mm
D 160mm
B 40mm
d2 112mm
D1 144mm
r1r2 min 2mm
s1 9.5mm
da min 101mm
da max 120mm
Da min 130mm
Da max 149mm
Ca 1.4mm
ra max 2mm
--- Speeds and Loads
Dynamic load C 325 kN
Static load Co 380 kN
Fatigue load limit Pu 42.5 kN
Reference speed 3800 rpm
Limiting speed 5300 rpm
--- Factors
Misalignment factor k1 0.104
Operating clearance factor k2 0.117
--- Weights
Weight 3.3 kg
--- Matching Adaptor Sleeves
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=H318E+sleeve>H318E</a>
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=HA318E+sleeve>HA318E</a>
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=HE318E+sleeve>HE318E</a>
--- Matching Withdrawal Sleeves
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=AHX318+sleeve>AHX318</a>
