• SKF C2211KTN9 Carb Toroidal Roller Bearing with Taper Bore 55x100x25mm Allow 7-10 Days
1 1

SKU: C2211KTN9-SKF

SKF C2211KTN9 Carb Toroidal Roller Bearing with Taper Bore 55x100x25mm Allow 7-10 Days

SKF C2211KTN9 Carb Toroidal Roller Bearing with Taper Bore 55x100x25mm Allow 7-10 Days
€185,95 ex VAT
€185,95 ex VAT
Sale Sold out

In stock

Price Break
10+ €141,27
19+ €133,33
29+ €131,75
39+ €130,16
49+ €128,57
74+ €126,98
99+ €119,05
199+ €117,46
249+ €115,87
499+ €114,29
999+ €111,11

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Carb Toroidal Roller Bearings: These compact design bearings have a single row of barrel shaped (spherical) rollers which run on a common spherical outer and inner raceway. Their design offers many features such as self alignment, insensitivity to misalignment, tolerance to heavy radial and axial loads etc. They are manufactured with in both parallel and tapered bore variants and the ability to deliberately displace the position of the rings to each other permits accurate setting of the radial internal clearance.
Benefits: High radial and axial loads, misalignment, taper and parallel bore options
Brand / Quality:
SKF - High Quality
Inside Diameter:
55mm
Outside Diameter:
100mm
Width:
25mm
Seals / Shields:
None
Technical
--- Dimensions
d 55mm
D 100mm
B 25mm
d2 65.8mm
D1 86.7mm
r1r2 min 1.5mm
s1 8.6mm
da min 64mm
da max 65mm
Da min 84mm
Da max 91mm
Ca 0.3mm
ra max 1.5mm
--- Speeds and Loads
Dynamic load C 116 kN
Static load Co 114 kN
Fatigue load limit Pu 13.4 kN
Reference speed 6700 rpm
Limiting speed 9000 rpm
--- Factors
Misalignment factor k1 0.094
Operating clearance factor k2 0.133
--- Weights
Weight 0.79 kg
--- Matching Adaptor Sleeves
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=H311E+sleeve>H311E</a>
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=HA311E+sleeve>HA311E</a>
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=HE311BE+sleeve>HE311BE</a>
--- Matching Withdrawal Sleeves
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=AHX311+sleeve>AHX311</a>
