• NSK 7932A5TRDULP3 Super Precision Angular Contact Spindle Bearing 160x220x28mm (Set of 2)
1 1

SKU: 7932A5TRDULP3-NSK

NSK 7932A5TRDULP3 Super Precision Angular Contact Spindle Bearing 160x220x28mm (Set of 2)

NSK 7932A5TRDULP3 Super Precision Angular Contact Spindle Bearing 160x220x28mm (Set of 2)
€2.951,95 ex VAT
€2.951,95 ex VAT
Sale Sold out

In stock

Price Break
3+ €2.242,76
5+ €2.116,76
10+ €2.091,56
25+ €2.066,36
49+ €2.041,16
74+ €2.015,96
99+ €1.889,97
199+ €1.864,77
249+ €1.839,57
499+ €1.814,37
999+ €1.763,97

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
5ZG1TM6ZIA
Brand / Quality:
NSK - High Quality
Inside Diameter:
160mm
Outside Diameter:
220mm
Width:
28mm
Seals / Shields:
None
Style:
Universal Matched Pair of Bearings
Contact Angle:
25 Degree contact angle
Bearing Preload:
Light preload
Technical
--- Bearing dimensions
d 160mm
D 220mm
B 28mm
r<sub>min</sub> 2mm
r1<sub>min</sub> 1mm
--- Loads angles and speeds
C<sub>r</sub> 105Kn
C<sub>or</sub> 125kN
Axial load Kn 93.5 kN
Contact angle 25 degrees
Factor f<sub>o</sub> -
Effective diameter 58.3mm
Max speed in grease 4800 rpm
Max speed in oil 7400 rpm
--- Fitting dimensions
d<sub>a min</sub> 170mm
D<sub>a max</sub> 210mm
D<sub>b max</sub> 214mm
r<sub>a max</sub> 2mm
r<sub>b max</sub> 1mm
Weight 6.24kg
