SKU: 712-152055A2

High-Performance 304 Stainless Steel Female/Female Anti-Vibration Bobbin 15x20mm M4 Threads

High-Performance 304 Stainless Steel Female/Female Anti-Vibration Bobbin 15x20mm M4 Threads

Out of stock


Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
D 15mm
D1 M4
D2 M4
L 20mm
L1 4mm
L2 4mm
Deflection at Max Compressive Load 1.8mm
Deflection at Max Sheer Load 3.6mm
Max Compressive Load 12.1 kg
Max Sheer Load 5.4 kg
Temperature Range -30 deg C to +80 deg C
Hardness 54 Shore A Hardness
Weight 0.02 kg
Nuts <a href="advanced_search_result.php?sort=2a&search_in_description=1&keywords=M4+steel+nut">M4 Click Here</a>
Set Screws <a href="advanced_search_result.php?sort=2a&search_in_description=1&keywords=M4+set+screw">M4 Click Here</a>
