• Timken 560/552A TS Single-Row Taper Roller Bearing 2.625x4.875x1.5 inch
1 1

SKU: 560/552A-TIM

Timken 560/552A TS Single-Row Taper Roller Bearing 2.625x4.875x1.5 inch

Timken 560/552A TS Single-Row Taper Roller Bearing 2.625x4.875x1.5 inch
€145,95 ex VAT
€145,95 ex VAT
Sale Sold out

In stock

Price Break
10+ €110,77
20+ €104,55
30+ €103,31
40+ €102,06
50+ €100,82
75+ €99,57
100+ €93,35
200+ €92,10
250+ €90,86
500+ €89,62
1000+ €87,13

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
JL_TAPER_DESC
Brand / Quality:
Timken - High Quality
Inside Diameter:
66.68mm = 2.625 (2-5/8) inch
Outside Diameter:
123.83mm = 4.875 (4-7/8) inch
Width:
38.1mm = 1.5 (1-1/2) inch
Technical
d 66.675mm = 2.625 inch
D 123.825mm = 4.875 inch
T 38.1mm = 1.5 inch
Dynamic (1) C1 177000N
Factors (5) e 0.35
Factors (5) Y 1.73
Dynamic (2) C90 45800N
Dynamic (2) Ca90 27100N
Factors (5) K 1.69
Static C0 248000N
Bearing B 36.678mm = 1.444 inch
Bearing C 30.162mm = 1.1875 inch
Bearing a(3) -9.4mm = -0.37 inch
Shaft max shaft fillet radius R(4) 3.5mm = 0.14 inch
Shaft backing shoulder diameter da 75mm = 2.95 inch
Shaft backing shoulder diameter db 81mm = 3.19 inch
Housing backing shoulder diameter r(4) 3.3mm = 0.13 inch
Housing backing shoulder diameter Da 116mm = 4.57 inch
Housing backing shoulder diameter Db 109mm = 4.29 inch
Cage Aa 2.3mm = 0.09 inch
Cage Ab 1.2mm = 0.05 inch
G1 91
G2 21.1
Cg 0.1108
