• Timken 32304 Metric Taper Roller Bearing 20x52x22.25mm
1 1

SKU: 32304-TIM

Timken 32304 Metric Taper Roller Bearing 20x52x22.25mm

Timken 32304 Metric Taper Roller Bearing 20x52x22.25mm
€42,95 ex VAT
€42,95 ex VAT
Sale Sold out

In stock

Price Break
10+ €32,40
20+ €30,58
30+ €30,21
40+ €29,85
50+ €29,48
75+ €29,12
100+ €27,30
200+ €26,94
250+ €26,57
500+ €26,21
1000+ €25,48
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Metric Taper Roller Bearings: These bearings have tapered inner and outer raceways between which tapered roller are arranged. The design of taper rollers makes them particularly suited to accommodating combined axial and radial loads. They are supplied as a cup and cone set (inner and outer).
Benefits: Used widely in transmissions, can be used in oil or greased, high radial and axial load
Brand / Quality:
Timken - High Quality
Inside Diameter:
20mm
Outside Diameter:
52mm
Width:
22.25mm
Technical
d 20mm
D 52mm
T 22.25mm
Dynamic load 44 kN
Static load 45.5 kN
Fatigue load limit Pu 5 kN
Reference speed 10000 rpm
Limiting speed 14000 rpm
Mass 0.23 kg
d1 34.5mm
B 21mm
C 18mm
r1r2 min 1.5mm
r3r4 min 1.5mm
a 14mm
da max 27mm
db min 27mm
Da min 43mm
Da max 45mm
Db min 47mm
Ca min 3mm
Cb min 4mm
ra max 1.5mm
rb max 1.5mm
e 0.3
Y 2
Y0 1.1
