SKU: 23060-K-MB+AH3060-FAG
FAG 23060KMB Spherical Roller Bearing with AH3060 Withdrawal Sleeve 280x460x118mm
FAG 23060KMB Spherical Roller Bearing with AH3060 Withdrawal Sleeve 280x460x118mm
Regular price
€6.147,95
ex VAT
Regular price
Sale price
€6.147,95
ex VAT
In stock
Price Break
3+
€4.681,69
4+
€4.418,67
9+
€4.366,07
19+
€4.313,46
29+
€4.260,86
39+
€4.208,26
49+
€3.945,24
59+
€3.892,64
249+
€3.840,04
499+
€3.787,43
999+
€3.682,23
Description
Description
- Brand / Quality:
- FAG - High Quality
- Inside Diameter:
- 280mm
- Outside Diameter:
- 460mm
- Width:
- 118mm
- Seals / Shields:
- None
- Clearance:
- * Standard
Technical
Technical
| d1H | 280mm |
|---|---|
| d | 300mm |
| D | 460mm |
| B | 118mm |
| r min | 4mm |
| D1 | 412.6mm |
| ds | 9.5mm |
| ns | 17.7mm |
| a | 8mm |
| b | 26mm |
| Thread d2G | Tr320X5 |
| l | 145mm |
| da min | 314.6mm |
| Da max | 445.4mm |
| ra max | 3mm |
| Dynamic load Cr | 1960000 N |
| Static load C0r | 3650000 N |
| e | 0.25 |
| Y1 | 2.69 |
| Y2 | 4 |
| Y0 | 2.63 |
| Fatigue load limit Cur | 223000 N |
| Limiting speed nG | 1100 rpm |
| Reference speed nB | 960 rpm |
| Bearing weight | 72.2 kg |
| Withdrawal sleeve weight | 14.3 kg |
