SKU: 16002-2Z/C3-NKE
NKE 160022ZC3 Metal Shielded Deep Groove Ball Bearing 15x32x8mm
Equivalent to: 160022ZC3 16002.2ZC3 16002.2ZC3 16002ZZC3 160022ZRC3 16002ZZEC3 16002ZZC3 16002.2ZC3 16002KDDC3 16002DDC3 160022ZRC3 16002FFC3 ABMA 15BC00 CASE IH V36091 CBF 16002 DAIM BENZ 625016002 ESK 16002 FAG 16002 FAUN 5000-002 GMN 16002 IMPEXMETAL 16002 KOYO 16002 NACHI 16002 NSK 16002 NTN 16002 RHP 16002 RIV EL15 SKF 16002 SMT 16002 SNR 16002 STEYR 16002 VBF 7000102 WIB 16002 ZVL ZKL 16002 61800-2Z-NKE 160022ZC3 61800-2Z/C3-NKE Two Metal Shields
In stock
Price Break
Couldn't load pickup availability
Description
|
Metal Shielded Deep Groove Ball Bearings: One of the most commonly used bearings, these types are manufactured with metal shields inserted into the outer raceway, these fit in closely to the inner race providing protection against light mechanical damage, some protection against the ingress of moisture, dust and other foreign matter and serve to retain the pre-filled grease in the bearing. |
- Brand / Quality:
- NKE - High Quality
- Inside Diameter:
- 15mm
- Outside Diameter:
- 32mm
- Width:
- 8mm
- Seals / Shields:
- Metal Shielded
- Clearance:
- C3
Technical
| d | 15mm |
|---|---|
| D | 32mm |
| B | 8mm |
| Dynamic load C | 5.85 kN |
| Static load Co | 2.85 kN |
| Fatigue load limit Pu | 0.12 kN |
| Reference speed | 50000 rpm |
| Limiting speed | 26000 rpm |
| Weight | 0.03 kg |
| d1 | 20.5mm |
| D2 | 28.2mm |
| r1r2 min | 0.3mm |
| da min | 17mm |
| Da max | 30mm |
| ra max | 0.3mm |
| Calculation factor kr | 0.025 |
| Calculation factor f0 | 14 |
