SKU: 1/MFC4-RHP

RHP 1/MFC4 Four Bolt Round Cast Iron Flanged Bearing Unit and 4 inch Insert

RHP 1/MFC4 Four Bolt Round Cast Iron Flanged Bearing Unit and 4 inch Insert

Out of stock


Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
Bore 4 inch
L 10.874 inch
H 8.125 inch
J 9.375 inch
G 0.75 inch
A1 3.5 inch
A4 1.625 inch
A5 0.5 inch
B 4.625 inch
s 1.94 inch
d1 5.242 inch
Dynamic load 19900 N
Static load 20860 N
Rec max speed 1550 rpm
Weight 20 kg
Insert <a href="advanced_search_result.php?keywords=205-4G+insonly">205-4G Click Here</a>
Casting group 1/11
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
