SKU: TA.6530.Z
IKO TA6530Z Needle Roller Bearing Open End Type 65x77x30mm
- Regular price
- €45,95 ex VAT
- Sale price
- €45,95
- Regular price
-
In stock
Quantity Price Breaks
10
€40,90
19
€38,60
29
€38,14
39
€37,68
49
€37,22
74
€36,76
99
€34,46
199
€34,00
249
€33,54
499
€33,08
999
€32,17
SKU:
TA.6530.Z
IKO TA6530Z Needle Roller Bearing Open End Type 65x77x30mm
- Regular price
- €45,95 ex VAT
- Sale price
- €45,95
- Regular price
-
Description
IKO TA Series Shell Type Drawn Cup Needle Roller Bearings: As the name suggests are needle roller bearings with deep drawn thin-walled outer rings with open ends. They are characterized by low sectional height and high load-carrying ability. They are ideal where a very compact and economical bearing arrangement is required
Benefits: Compact low cross-section design, high load bearing, low cost and economical, Requires only a bored housing for deployment, the simplest of housing designs.
Technical
| Fw | = | 65mm |
| D | = | 77mm |
| C | = | 30mm |
| Dynamic load | = | 68500 N |
| Static load | = | 149000 N |
| Inner race | = | IRT5530 |
| Weight | = | 191 g |
