SKU: 53308+U308-EU
53308 Budget Single Thrust Ball Bearing with Spherical Housing Seat U308 40x78x31mm
- Regular price
- €49,95 ex VAT
- Sale price
- €49,95
- Regular price
-
Not in stock
Quantity Price Breaks
10
€44,46
19
€41,96
29
€41,46
39
€40,96
49
€40,46
74
€39,96
99
€37,46
199
€36,96
249
€36,46
499
€35,96
999
€34,97
SKU:
53308+U308-EU
53308 Budget Single Thrust Ball Bearing with Spherical Housing Seat U308 40x78x31mm
- Regular price
- €49,95 ex VAT
- Sale price
- €49,95
- Regular price
-
Description
|
Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
Technical
| d | = | 40mm |
| D | = | 78mm |
| H1 | = | 31mm |
| Dynamic load C | = | 61.8 kN |
| Static load Co | = | 122 kN |
| Fatigue load limit Pu | = | 4.5 kN |
| Minimum load factor A | = | 0.077 |
| Reference speed | = | 3000 rpm |
| Limiting Speed | = | 4300 rpm |
| Weight | = | 0.67 kg |
| Seating Washer | = | U308 |
| d1 | = | 78mm |
| D1 | = | 42mm |
| D2 | = | 60mm |
| D3 | = | 82mm |
| H | = | 28.5mm |
| C | = | 8.5mm |
| R | = | 64mm |
| s | = | 28mm |
| r1r2 min | = | 1mm |
| da max | = | 63mm |
| Da max | = | 60mm |
| ra max | = | 1mm |
